VEX 259
Flecte
Great Value
Best in Class family of
CNC mandrel tube bending machines
- Full electric 25mm/od mandrel tube bending machine
- Multiple stacks – 9 CNC axis
- For a variety of tube profiles with fixed radius mandrel bending and capable of variable radius roll bending in the same bending process.
- See full technical specification below
- Optional extras include: auto load / off load systems – Tooling
- Full UK parts and labour warranty, support and back up – “We look after our customers“
Technical Specification
Maximum Tube Diameter | 25 |
Number of Electric Servo Axis | 9 |
Number of Tooling Stacks | Multiple |
Machine Length | 3800 |
Machine Width | 930 |
Machine Height | 1500 |
Machine Weight | 1700 kg |
Electrical Power Consumption | 12 Kw |
Maximum Tube Length Over Mandrel | 3000 |
Maximum Bend Centre Line Radius | 150 |
Maximum Tube Bending Speed (°/sec) | 200 |
Tube Feeding Speed (mm/sec) | 1150 |
Tube Rotation Speed (°/sec) | 560 |
Bending Accuracy (degrees) | 0.05 |
To summaries:
* Budget priced CNC mandrel tube bending machine for the most demanding applications.
* Includes: UK installation, commissioning, and operator training
* Complete with on-going service, support and back-up.
Got questions – Book a live or remote demonstration – or need assistance?
Please feel free to let us know. We’re a friendly bunch (after coffee) and here to:
Help you get it right – It’s what we do! – Quotation available up on request
Your local contact is:
John Owen
Fluent in CNC tube bending
Direct dial: +44(0)7776 213919
