Vex 905
Vex 905
- Hybrid tube / pipe bending machine
- Capable of bending tube sizes up to: 90mm/od x 5mm/wt
- Multiple stacks
- 5 CNC axis
- Fixed and variable radius bending
- See full technical specification below
- Optional extras:
- Auto load / off load systems
- Tooling
- Full UK parts and labour warranty, support and after sale back up
- “We look after our customers“
CNC machines and systems. Built to meet the most complex challenging designs
There are a load of benefits to unpack. We offer complete consultation and step by step advice to accompany your project from planning through to commissioning
Technical Specification
| Maximum Tube Diameter | 90 |
| Number of Electric Servo Axis | 5 |
| Number of Tooling Stacks | Multiple |
| Machine Length | 7200 |
| Machine Width | 1360 |
| Machine Height | 1600 |
| Machine Weight | 6000 kg |
| Electrical Power Consumption | 35 Kw |
| Maximum Tube Length Over Mandrel | 6300 |
| Maximum Bend Centre Line Radius | 200 |
| Maximum Tube Bending Speed (°/sec) | 65 |
| Tube Feeding Speed (mm/sec) | 800 |
| Tube Rotation Speed (°/sec) | 350 |
| Bending Accuracy (degrees) | 0.05 |
To summaries:
* Deluxe CNC mandrel tube bending machine for the most demanding applications.
* Includes: UK installation, commissioning, and operator training
* Complete with on-going service, support and back-up.
A live or remote demonstration can be
arranged and is recommended
